NVIDIA NeMo Agent Toolkit Tutorial 1.3 with LangChain/LangGraph in November 2025

At first glance, NVIDIA NeMo Agent Toolkit (NAT) can seem overwhelming. With its extensive documentation, multiple agent types (ReAct, ReWOO, Reasoning, Router), and enterprise-grade features, it’s easy to wonder: “Why not just use LangChain or CrewAI?”

The truth is, NAT isn’t meant to replace these frameworks—it’s designed to work alongside them. NAT is a framework-agnostic library that provides production-ready observability, profiling, evaluation, and orchestration capabilities that are often missing or require significant custom development in pure LangChain or CrewAI setups. While it may take more time to learn initially, the step-by-step tutorial below will help you see how its powerful features can dramatically improve your agent development workflow.

What is NVIDIA NeMo Agent Toolkit?

NVIDIA NeMo Agent Toolkit is a flexible, lightweight, and unifying library that allows you to easily connect existing enterprise agents to data sources and tools across any framework. Think of it as a “composable operating system” for AI agents: every agent, tool, and workflow exists as a reusable function call that works seamlessly with LangChain, LlamaIndex, CrewAI, Microsoft Semantic Kernel, Google ADK, and your own custom frameworks.

Why Choose NVIDIA NeMo Agent Toolkit Over Pure LangChain or CrewAI?

While LangChain and CrewAI excel at building agents, NAT fills critical gaps in production deployment, observability, and enterprise integration. Here’s how they compare:

Feature	NVIDIA NAT	Pure LangChain	CrewAI
Framework Integration	✅ Works alongside LangChain, CrewAI, LlamaIndex, and custom frameworks	⚠️ LangChain-specific ecosystem	⚠️ CrewAI-specific ecosystem
Built-in Profiling	✅ End-to-end workflow profiling with token tracking, timing analysis, and bottleneck identification	❌ Requires custom instrumentation	❌ Limited profiling capabilities
Observability	✅ Native integrations with Phoenix, Weave, Langfuse, Dynatrace, OpenTelemetry, Galileo, and more	⚠️ Requires third-party integration setup	⚠️ Requires third-party integration setup
Evaluation System	✅ Built-in evaluation framework with dataset handlers and custom evaluators	⚠️ Requires LangSmith or custom setup	❌ Limited built-in evaluation
MCP Support	✅ Full Model Context Protocol support (client and server)	⚠️ Limited MCP support	❌ No native MCP support
UI Interface	✅ Built-in chat interface for testing and debugging workflows	❌ No built-in UI	❌ No built-in UI
Code Execution Sandbox	✅ Built-in secure code execution environment	⚠️ Requires external sandbox setup	❌ No built-in sandbox
Memory & Retrieval	✅ Integrated memory module with multiple retriever providers (Milvus, NeMo, custom)	⚠️ Requires separate integration	⚠️ Requires separate integration
Production Deployment	✅ Sizing calculator, telemetry exporters, and deployment-ready configurations	⚠️ Requires custom deployment setup	⚠️ Requires custom deployment setup
Function Reusability	✅ Everything is a composable function call—build once, reuse anywhere	⚠️ More tightly coupled to framework	⚠️ More tightly coupled to framework
Multi-Agent Orchestration	✅ Router Agent, Sequential Executor, and flexible control flow	✅ Supports multi-agent patterns	✅ Specializes in multi-agent workflows
Enterprise Features	✅ Authentication providers, secure token storage, gated fields, registry system	⚠️ Basic security features	⚠️ Basic security features

The bottom line: If you’re building production agents that need observability, evaluation, and enterprise-grade features, NAT provides these capabilities out-of-the-box. You can continue using LangChain or CrewAI for your core agent logic while leveraging NAT’s advanced tooling for everything else. This tutorial will walk you through setting up your first NAT workflow to see these benefits in action.

What We’ll Build

In this tutorial, we’ll create a ReAct agent using LangChain and enhance it with NVIDIA NeMo Agent Toolkit. This demonstrates NAT’s true power: you don’t need to abandon your existing LangChain code. Instead, we’ll bring our LangChain agent into NAT to unlock production-grade observability, profiling, and enterprise features without rewriting everything from scratch.

Agent Overview

We’re building a web-enabled research agent that can:

Search the web for current information using DuckDuckGo Search
Get the current date and time to ensure searches retrieve the latest information
Reason through multi-step queries that require combining web search results with temporal context
Respond to questions that need up-to-date information

Technical Stack

Component	Technology	Details
Agent Framework	LangChain	We’ll build the core agent logic using LangChain
Agent Type	ReAct Agent	Reasoning + Acting loop for iterative problem-solving
LLM	Local model via Docker Model Runner	Uses OpenAI-compatible API standard (we’ll configure `base_url` and `api_key`)
Web Search Tool	DuckDuckGo Search (`ddgs`)	Real-time web search capabilities
Datetime Tool	NAT built-in datetime tools	Provides current date/time context for time-sensitive queries

The Power of Bringing Existing Agents into NAT

This tutorial demonstrates one of NAT’s most compelling features: framework-agnostic integration. Here’s why this matters:

Scenario: You’ve already built a production LangChain agent that works well. But now you need:

✅ End-to-end workflow profiling to identify bottlenecks
✅ Token usage tracking and cost optimization
✅ Production observability with Phoenix, Weave, or Langfuse
✅ Built-in evaluation framework
✅ Secure code execution sandboxes
✅ Enterprise authentication and deployment features

Traditional approach: Rewrite your agent from scratch or build custom instrumentation—weeks of work.

With NAT: Wrap your existing LangChain agent in NAT’s workflow builder. Your LangChain code stays exactly the same, but now it gains:

Automatic profiling and observability
Built-in evaluation capabilities
Enterprise-grade deployment features
Seamless integration with other NAT components

This is framework-agnostic development at its best: Build with the framework you know (LangChain), enhance with the features you need (NAT), without rewriting a single line of agent logic.

Why This Showcases NAT’s Power

This simple agent demonstrates several key NAT advantages that would require significant custom development in pure LangChain:

Framework Compatibility: Keep your LangChain code while adding NAT’s advanced features—no rewrite required
Seamless Local LLM Integration: NAT handles the OpenAI-compatible interface configuration cleanly, making it easy to swap between local and cloud models
Tool Composition: Multiple tools (web search + datetime) work together through NAT’s function composition system
Built-in Observability: We’ll see how NAT tracks tool calls, token usage, and timing automatically—without custom instrumentation
Production-Ready from Day One: The agent we build will have profiling and monitoring capabilities built-in, not added later

Example Use Cases

Our agent will be able to answer questions like:

“Who won the Chiefs versus Commanders football game? What was the score and who was the MVP?”
“What are the current top headlines in technology?”
“Find recent news about AI agents and developments in the past month”

Let’s dive into building it step-by-step.

Installation

Before we start building, we need to install NVIDIA NeMo Agent Toolkit and its dependencies. Since we’re using LangChain in this tutorial, we’ll install NAT with the LangChain plugin support.

Prerequisites

Python 3.11, 3.12, or 3.13 (supported platforms)
uv (version 0.5.4 or later) - We’ll use uv for fast, reliable package management

If you don’t have uv installed, you can install it using or go to uv installation guide for your installation choice:

pipx install uv

Install NVIDIA NeMo Agent Toolkit

We’ll install NAT with the LangChain/LangGraph integration plugin. According to the official installation guide, you can install optional dependencies using extras:

uv pip install "nvidia-nat[langchain]"
# or
uv pip install nvidia-nat-langchain

This single command installs:

The core nvidia-nat package
The LangChain/LangGraph plugin (nvidia-nat-langchain)
All required dependencies for framework integration

Verify Installation

After installation, verify that NAT is installed correctly:

nat --help
nat --version

You should see the NAT help message and version information, confirming the installation was successful.

Create a New Workflow Project

NVIDIA NeMo Agent Toolkit provides a powerful scaffolding command that creates a complete, production-ready workflow structure for you. According to the official tutorial guide, the nat workflow create command generates an organized project structure that separates concerns and makes customization straightforward.

Let’s create our workflow project:

nat workflow create web_search_agent

This command scaffolds a complete workflow project. Here’s what it creates and why the structure matters:

Project Structure Overview

The scaffolding creates a well-organized directory structure that follows NAT’s best practices:

web_search_agent/
├── configs -> src/web_search_agent/configs  # Symlink to config directory (DO NOT EDIT THIS FILE)
├── data -> src/web_search_agent/data          # Symlink to data directory (DO NOT EDIT THIS FILE)
├── pyproject.toml                             # Package metadata & dependencies
└── src/                                        # Source code directory (DO EDIT FROM THIS DIRECTORY)
    └── web_search_agent/
        ├── __init__.py
        ├── configs/
        │   └── config.yml                      # Workflow configuration (YAML)
        ├── data/                              # Data files directory
        ├── register.py                        # Function registration entry point
        └── web_search_agent.py                # Your custom tool/function

Understanding Each Component

1. pyproject.toml - Package Configuration This file declares your workflow as a Python package with:

Package metadata: Name, version, description
Dependencies: Declares dependency on nvidia-nat[langchain]
Entry points: Tells NAT where to find your workflow registration

The entry point configuration looks like:

[project.entry-points.'nat.plugins']
web_search_agent = "web_search_agent.register"

This tells NAT: “When loading the web_search_agent workflow, look in the web_search_agent.register module.”

2. src/web_search_agent/configs/config.yml - Workflow Configuration This is where you define your workflow’s runtime behavior:

LLM configuration (model, temperature, etc.)
Function/tool definitions
Agent type and settings
Workflow orchestration logic

The configs/ symlink at the root level provides convenient access to this configuration file, but the actual file lives in src/web_search_agent/configs/config.yml.

You’ll customize this file to:

Configure your local Docker Model Runner LLM
Register your web search and datetime tools
Set up the ReAct agent

3. src/web_search_agent/register.py - Registration Module This file registers your custom functions with NAT. It’s the bridge between your LangChain code and NAT. Here you’ll:

Import and register your custom tools
Connect LangChain functions to NAT’s function system
Define function metadata and descriptions

4. src/web_search_agent/web_search_agent.py - Custom Functions This is where you’ll write your LangChain-based tools:

DuckDuckGo web search tool
Datetime tool integration
Any other custom functions your agent needs

5. src/web_search_agent/data/ - Data Directory Optional directory for storing data files, sample inputs, or test data that your workflow might use.

Why This Structure Helps

Separation of Concerns:

Configuration (configs/ symlink → src/web_search_agent/configs/) is separate from code (src/), making it easy to swap configurations without changing logic
Registration (register.py) is separate from implementation (web_search_agent.py), allowing clean organization
Data (data/ symlink → src/web_search_agent/data/) is isolated from code, making it easy to version and manage separately

Organization Benefits:

Easy customization: Each file has a clear purpose—modify configs for runtime changes, modify functions for logic changes
Package distribution: The structure is ready for packaging and distribution as a Python package
Framework integration: The register.py file makes it straightforward to integrate LangChain code into NAT’s workflow system

Where You’ll Customize:

src/web_search_agent/configs/config.yml (or via configs/config.yml symlink): Add LLM settings, tool configurations, agent parameters
src/web_search_agent/web_search_agent.py: Write your LangChain tools (web search, datetime, etc.)
src/web_search_agent/register.py: Register your tools with the @register_function decorator
pyproject.toml: Add any additional dependencies (like ddgs)
src/web_search_agent/data/: Store any data files or test inputs your workflow needs

This scaffolding gives you a solid foundation. Next, we’ll customize these files to build our web-enabled research agent.

Additional Dependencies

For our web search functionality, we’ll also need DuckDuckGo Search. The package will automatically be added to the pyproject.toml file.

uv add ddgs

Customize the Workflow

Creating the Web Search Agent

Now let’s create our web search agent. We’ll customize src/web_search_agent/web_search_agent.py to build a ReAct agent that integrates LangChain with NVIDIA NeMo Agent Toolkit. Let’s break down the code to understand how NAT structures agent functions and why this pattern is powerful.

Here’s the complete code for src/web_search_agent/web_search_agent.py:

import logging

from pydantic import Field

from nat.builder.builder import Builder
from nat.builder.framework_enum import LLMFrameworkEnum
from nat.builder.function_info import FunctionInfo
from nat.cli.register_workflow import register_function
from nat.data_models.function import FunctionBaseConfig
from nat.data_models.component_ref import LLMRef, FunctionRef

logger = logging.getLogger(__name__)


class WebSearchAgentFunctionConfig(FunctionBaseConfig, name="web_search_agent"):
    """
    NAT function template. Please update the description.
    """
    llm_ref: LLMRef = Field(description="LLM name to use")
    tools_ref: list[FunctionRef] = Field(default_factory=list, description="List of tool names to use")
    max_iterations: int = Field(default=15, description="Maximum number of iterations to run the agent")
    handle_parsing_errors: bool = Field(default=True, description="Whether to handle parsing errors")
    verbose: bool = Field(default=True, description="Whether to print verbose output")


@register_function(config_type=WebSearchAgentFunctionConfig, framework_wrappers=[LLMFrameworkEnum.LANGCHAIN])
async def web_search_agent_function(_config: WebSearchAgentFunctionConfig, _builder: Builder):

    from langchain import hub
    from langchain.agents import AgentExecutor, create_react_agent

    tools = await _builder.get_tools(_config.tools_ref, wrapper_type=LLMFrameworkEnum.LANGCHAIN)
    llm = await _builder.get_llm(_config.llm_ref, wrapper_type=LLMFrameworkEnum.LANGCHAIN)

    prompt = hub.pull("hwchase17/react")

    react_agent = create_react_agent(
        llm=llm,
        tools=tools,
        prompt=prompt,
        stop_sequence=["\nObservation"]
    )

    agent_executor = AgentExecutor(
        agent=react_agent,
        tools=tools,
        **_config.model_dump(include={"max_iterations", "handle_parsing_errors", "verbose"})
    )

    async def _response_fn(input_message: str) -> str:
        response = await agent_executor.ainvoke({"input": input_message, "chat_history": []})

        return response["output"]

    yield FunctionInfo.from_fn(_response_fn)

Let’s break down each part to understand why NAT structures agent functions this way:

Understanding the Imports

from nat.builder.builder import Builder
from nat.builder.framework_enum import LLMFrameworkEnum
from nat.builder.function_info import FunctionInfo
from nat.cli.register_workflow import register_function
from nat.data_models.function import FunctionBaseConfig
from nat.data_models.component_ref import LLMRef, FunctionRef

Why these imports matter:

Builder: This is NAT’s dependency injection system. Instead of manually constructing LLMs and tools, Builder provides them based on your configuration. This enables NAT’s powerful features: automatic profiling, observability, and framework abstraction.
LLMFrameworkEnum.LANGCHAIN: Tells NAT we’re using LangChain, not LlamaIndex or CrewAI. NAT wraps framework-specific code so it can add observability without changing your LangChain code.
FunctionInfo: This is how NAT treats everything as a function call. By wrapping your agent in FunctionInfo, NAT can track token usage, timing, and failures automatically.
register_function: This decorator registers your function with NAT’s registry system. NAT discovers and loads workflows dynamically, so you don’t need manual wiring.
FunctionBaseConfig: NAT uses Pydantic models for all configurations. This provides validation, type safety, and allows NAT to understand your function’s requirements without executing code.
LLMRef and FunctionRef: These are references to components defined in your config.yml, not the components themselves. This separation allows you to swap LLMs or tools without changing code—just update the config file.

The Configuration Class: `WebSearchAgentFunctionConfig`

class WebSearchAgentFunctionConfig(FunctionBaseConfig, name="web_search_agent"):
    llm_ref: LLMRef = Field(description="LLM name to use")
    tools_ref: list[FunctionRef] = Field(default_factory=list, description="List of tool names to use")
    max_iterations: int = Field(default=15, description="Maximum number of iterations to run the agent")
    handle_parsing_errors: bool = Field(default=True, description="Whether to handle parsing errors")
    verbose: bool = Field(default=True, description="Whether to print verbose output")

Why configuration classes exist:

In traditional frameworks, you might hardcode settings or pass dictionaries. NAT uses Pydantic configuration classes for several reasons:

Validation: Invalid configs are caught at startup, not during execution
Type safety: Your IDE knows exactly what fields exist and their types
Documentation: The description fields become documentation in NAT’s CLI and UI
Dependency references: llm_ref and tools_ref are references to components in your config.yml. This means:
- You can swap LLMs without changing code
- NAT can track which LLM was used for each execution
- Different workflows can reuse the same function with different LLMs/tools

The name="web_search_agent" parameter: This tells NAT what name to use when loading this function from config.yml. When you write _type: web_search_agent in your config, NAT looks for this class.

The Registration Decorator

@register_function(config_type=WebSearchAgentFunctionConfig, framework_wrappers=[LLMFrameworkEnum.LANGCHAIN])
async def web_search_agent_function(_config: WebSearchAgentFunctionConfig, _builder: Builder):

Why this pattern matters:

config_type: Tells NAT which configuration class to use when parsing your config.yml. NAT automatically validates the YAML against this Pydantic model.
framework_wrappers=[LLMFrameworkEnum.LANGCHAIN]: This is crucial. It tells NAT: “This function uses LangChain, so wrap any LangChain objects with NAT’s observability layer.” NAT intercepts LangChain calls to add:
- Token counting (input/output tokens)
- Timing information (how long each tool call takes)
- Error tracking and retry logic
- Integration with observability platforms (Phoenix, Weave, etc.)
Without this, NAT can’t add observability to your LangChain code. With it, your LangChain code gains production features automatically.
async function: NAT uses async functions because modern LLM APIs are async, and NAT needs to orchestrate multiple components efficiently.
_builder: Builder: This is NAT’s dependency injection container. You never directly construct LLMs or tools—you ask Builder for them. This is how NAT:
- Tracks which components are used together
- Adds profiling automatically
- Manages component lifecycle
- Supports framework-agnostic workflows

Getting Components from Builder

tools = await _builder.get_tools(_config.tools_ref, wrapper_type=LLMFrameworkEnum.LANGCHAIN)
llm = await _builder.get_llm(_config.llm_ref, wrapper_type=LLMFrameworkEnum.LANGCHAIN)

Why Builder is powerful:

Instead of:

# Traditional approach - tightly coupled
llm = ChatOpenAI(model="gpt-4", api_key="...")
tools = [search_tool, datetime_tool]

You use:

# NAT approach - framework-agnostic and observable
tools = await _builder.get_tools(_config.tools_ref, wrapper_type=LLMFrameworkEnum.LANGCHAIN)
llm = await _builder.get_llm(_config.llm_ref, wrapper_type=LLMFrameworkEnum.LANGCHAIN)

Benefits:

Configuration-driven: LLM and tools come from config.yml, not hardcoded.
Framework abstraction: wrapper_type=LLMFrameworkEnum.LANGCHAIN means you get LangChain objects, but NAT wraps them for observability.
Automatic tracking: NAT logs which tools were called, how long they took, and what tokens were used.
Easy swapping: Change config.yml to use a different LLM or tool set without touching code.

_config.tools_ref: This is a list of FunctionRef objects from your config. Each reference points to a tool function (like web_search or current_datetime) defined elsewhere. Builder resolves these references and returns the actual LangChain tool objects.

Creating the LangChain Agent

from langchain import hub
from langchain.agents import AgentExecutor, create_react_agent

prompt = hub.pull("hwchase17/react")

react_agent = create_react_agent(
    llm=llm,
    tools=tools,
    prompt=prompt,
    stop_sequence=["\nObservation"]
)

agent_executor = AgentExecutor(
    agent=react_agent,
    tools=tools,
    **_config.model_dump(include={"max_iterations", "handle_parsing_errors", "verbose"})
)

This is pure LangChain code—no NAT-specific changes needed! Here’s what happens:

hub.pull("hwchase17/react"): Loads the standard ReAct prompt from LangChain Hub. This is the prompt template that tells the agent how to reason and act.
create_react_agent: Creates a ReAct agent. The llm and tools you pass are LangChain objects, but they’ve been wrapped by NAT for observability. Your LangChain code works exactly as it would without NAT.
AgentExecutor: This is LangChain’s agent executor. The **_config.model_dump(...) extracts configuration fields (max_iterations, handle_parsing_errors, verbose) and passes them to the executor.

Key insight: Your LangChain code stays pure LangChain. NAT doesn’t require you to change how you write agents—it wraps them transparently.

The Response Function

async def _response_fn(input_message: str) -> str:
    response = await agent_executor.ainvoke({"input": input_message, "chat_history": []})
    return response["output"]

yield FunctionInfo.from_fn(_response_fn)

Why yield a function instead of returning a value:

NAT uses a generator pattern (yield) instead of returning a value directly. This is because NAT functions can return multiple things:

Multiple tools (one function can register multiple tools)
Streaming responses
Partial results during execution

FunctionInfo.from_fn(_response_fn) wraps your function so NAT can:

Track when it’s called
Log input/output
Measure performance
Handle errors automatically
Integrate with observability platforms

The _response_fn closure: This inner function captures the agent_executor (which contains your configured LangChain agent). When NAT calls this function later, it invokes your LangChain agent with the provided input message.

Why This Structure Matters

This pattern—configuration class, registration decorator, Builder dependency injection, and function yielding—is what makes NAT powerful:

Framework-agnostic: The same function pattern works with LangChain, LlamaIndex, or CrewAI—just change framework_wrappers
Configuration-driven: Swap LLMs, tools, and parameters via config.yml without code changes
Observable by default: Every function call is automatically tracked, profiled, and logged
Composable: Functions can reference other functions, creating reusable workflows
Production-ready: Error handling, retries, and telemetry are built-in, not added later

Next, we’ll see how to register this function and create the tools it uses.

Registering the Function: `register.py`

Now let’s look at src/web_search_agent/register.py. This is the entry point that NAT uses to discover and load your workflow functions. Here’s what it contains:

# flake8: noqa

# Import the generated workflow function to trigger registration
from .web_search_agent import web_search_agent_function

Why this file is simple but important:

At first glance, this looks trivial—just importing a function. But this pattern is key to how NAT’s registration system works.

How Python decorators work:

When Python imports a module, it executes all the code in that module, including decorators. When you write:

@register_function(config_type=WebSearchAgentFunctionConfig, framework_wrappers=[LLMFrameworkEnum.LANGCHAIN])
async def web_search_agent_function(...):
    ...

The @register_function decorator executes immediately when the module is imported. The decorator:

Takes the function object
Registers it in NAT’s internal registry
Associates it with the configuration class (WebSearchAgentFunctionConfig)
Marks it as using LangChain framework wrappers

Why this pattern matters:

1. Automatic discovery: NAT doesn’t require you to manually register functions. When NAT loads your workflow package (via the entry point in pyproject.toml), it imports register.py, which imports your function, which triggers the decorator, which registers everything automatically.

2. Lazy registration: Functions are registered when the module is imported, not when NAT starts. This means:

You can have multiple workflow packages installed
NAT only loads the workflows you actually use
Registration happens automatically without manual wiring

3. Entry point pattern: Remember from pyproject.toml:

[project.entry-points.'nat.plugins']
web_search_agent = "web_search_agent.register"

When you run nat run --config_file config.yml, NAT:

Reads the config file to find which workflow to use
Looks up the entry point (web_search_agent.register)
Imports that module (from web_search_agent.register import *)
The import triggers all the @register_function decorators
Functions are now registered and available for use

The flake8: noqa comment:

This tells the code linter (flake8) to ignore this file. Why? Because this file only contains imports. From a linting perspective, importing something you don’t use looks like an error. But in NAT’s pattern, the import’s side effect (registration) is the purpose. The noqa comment acknowledges: “Yes, we’re intentionally importing for side effects, and that’s okay.”

Why this structure helps:

Separation of concerns: Registration logic is in the decorator, not in register.py. The register.py file is just a manifest of what functions exist.
Easy to extend: Want to add more functions? Just import them in register.py:

# Import the generated workflow function to trigger registration
from .web_search_agent import web_search_agent_function
from .another_tool import another_tool_function  # Add more functions easily

Framework-agnostic: The same pattern works whether you’re registering LangChain, LlamaIndex, or CrewAI functions—the decorator handles the differences.

What happens when NAT runs:

You run: nat run --config_file configs/config.yml --input "your question"
NAT reads config.yml and finds: _type: web_search_agent
NAT looks up the entry point: web_search_agent.register
NAT imports: from web_search_agent.register import *
Python executes the import, which triggers @register_function decorator
The decorator registers web_search_agent_function in NAT’s registry
NAT can now resolve _type: web_search_agent to the registered function
NAT creates the function with your configuration and executes it

All of this happens automatically—you never manually wire functions together.

Key takeaway: The register.py file is minimal by design. It’s not where you write logic—it’s where you declare what functions exist. The actual registration happens automatically via Python decorators when the module is imported. This is NAT’s “convention over configuration” approach: follow the pattern, and registration happens automatically.

Configuring the Workflow: `config.yml`

Now let’s configure our workflow using src/web_search_agent/configs/config.yml. This is where we wire everything together—defining LLMs, tools, and how they connect. Here’s the configuration file:

functions:
  datetime:
    _type: current_datetime

embedders:
  docker_embedder:
    _type: openai
    base_url: "http://localhost:12434/embeddings/v1"
    api_key: "docker"
    model: embeddinggemma

llms:
  docker_llm:
    _type: openai
    base_url: "http://localhost:12434/engines/v1"
    api_key: "docker"
    model: hf.co/bartowski/nvidia_nvidia-nemotron-nano-12b-v2-gguf
    temperature: 0.0

  niprgpt_llm:
    _type: openai
    base_url: $NIPRGPT_URL
    api_key: $NIPRGPT_API_KEY
    model: $NIPRGPT_MODEL
    temperature: 0.7

workflow:
  _type: web_search_agent
  llm_ref: docker_llm
  tools_ref: [datetime]
  max_iterations: 15
  verbose: false
  description: "A web search agent that uses the search and datetime tools to answer questions"

Let’s break down each section to understand why NAT structures configurations this way:

Understanding the Configuration Structure

NAT uses a hierarchical configuration structure with clear sections. Each section defines a type of component that can be referenced elsewhere. Here’s what each section does:

1. functions: — Tool Definitions

functions:
  datetime:
    _type: current_datetime

Why this section exists:

functions: defines reusable tools/functions that your workflow can use. Each function has a name (like datetime) and a type (like current_datetime).
The _type field: This tells NAT which function to load. NAT looks for a registered function with that name. For example, _type: current_datetime tells NAT: “Find the function registered with the name ‘current_datetime’ and use it.”
Function names as references: The key (datetime) becomes a reference that can be used elsewhere. When you write tools_ref: [datetime], NAT looks up this name in the functions: section.

Why NAT uses this pattern:

Separation of concerns: Tools are defined once, referenced many times.
Easy swapping: Change _type: current_datetime to a custom datetime function without changing code.
Composition: Multiple workflows can reuse the same function definitions.

2. llms: — LLM Configuration

llms:
  docker_llm:
    _type: openai
    base_url: "http://localhost:12434/engines/v1"
    api_key: "docker"
    model: hf.co/bartowski/nvidia_nvidia-nemotron-nano-12b-v2-gguf
    temperature: 0.0

Why this section exists:

llms: defines LLM configurations. Each LLM has a name (docker_llm) and configuration parameters (_type, base_url, api_key, model, temperature).
_type: openai: This tells NAT to use the OpenAI-compatible provider. NAT supports multiple provider types (OpenAI, Anthropic, custom, etc.), and _type determines how NAT interprets the configuration.
LLM names as references: The key (docker_llm) becomes a reference. When you write llm_ref: docker_llm in the workflow section, NAT looks up this name in the llms: section.

Why this pattern is powerful:

Instead of hardcoding LLM settings in your code:

# Traditional approach - hardcoded
llm = ChatOpenAI(
    model="gpt-4",
    api_key="...",
    temperature=0.0
)

You configure them in YAML:

# NAT approach - configuration-driven
llms:
  docker_llm:
    model: hf.co/bartowski/nvidia_nvidia-nemotron-nano-12b-v2-gguf
    temperature: 0.0

Benefits:

Swap LLMs without code changes: Change llm_ref: docker_llm to llm_ref: niprgpt_llm to use a different LLM.
Environment-specific configs: Different config files can use different LLMs (local vs. cloud).
Automatic observability: NAT tracks which LLM was used for each execution automatically.

3. niprgpt_llm: — Alternate LLM Configuration with Environment Variables

niprgpt_llm:
  _type: openai
  base_url: $NIPRGPT_URL
  api_key: $NIPRGPT_API_KEY
  model: $NIPRGPT_MODEL
  temperature: 0.7

Why this section exists and how secrets work:

niprgpt_llm: defines an alternate LLM configuration that uses environment variables for sensitive information like API keys and URLs.
For now, we won’t use niprgpt_llm—we’ll focus on getting the agent running with docker_llm first. But I included this section to demonstrate how to configure LLMs using environment variables for secrets.

How NAT handles secrets with environment variables:

NAT supports environment variable substitution in configuration files using the $VARIABLE_NAME syntax. When NAT loads your configuration, it automatically replaces $VARIABLE_NAME with the value of that environment variable.

Where to store secrets:

Create a .env file in your project root directory (or wherever you’re running NAT from) to store sensitive information:

# .env file
NIPRGPT_URL=https://api.example.com/v1
NIPRGPT_API_KEY=sk-your-api-key-here
NIPRGPT_MODEL=gpt-4-turbo

How NAT references environment variables:

In your config file: Use $VARIABLE_NAME syntax:

base_url: $NIPRGPT_URL
api_key: $NIPRGPT_API_KEY
model: $NIPRGPT_MODEL

When NAT loads the config: NAT automatically:
- Reads environment variables from your shell or .env file
- Substitutes $VARIABLE_NAME with the actual value
- Uses the substituted values in the configuration

Benefits of using environment variables:

Security: Never commit secrets to version control—keep them in .env files (which should be in .gitignore)
Environment-specific configs: Different environments (development, staging, production) can use different .env files
Easy swapping: Change llm_ref: docker_llm to llm_ref: niprgpt_llm to switch between local and cloud LLMs
Secret management: Integrate with secret management systems (HashiCorp Vault, AWS Secrets Manager, etc.) that set environment variables

Note: Make sure your .env file is in .gitignore to avoid committing secrets:

# .gitignore
.env
.env.local

4. embedders: — Embedding Model Configuration

embedders:
  docker_embedder:
    _type: openai
    base_url: "http://localhost:12434/embeddings/v1"
    api_key: "docker"
    model: embeddinggemma

Why this section exists:

embedders: defines embedding model configurations. Embedders are used for vector search, retrieval, and similarity calculations.
For now, we won’t use embedders—we’ll focus on getting the agent running first. But NAT includes this section because many workflows need embedding models for retrieval-augmented generation (RAG).

5. workflow: — The Main Workflow

workflow:
  _type: web_search_agent
  llm_ref: docker_llm
  tools_ref: [datetime]
  max_iterations: 15
  verbose: false
  description: "A web search agent that uses the datetime tool to answer questions"

This is where everything comes together. This section tells NAT:

_type: web_search_agent: Use the function we registered with @register_function and name="web_search_agent". NAT looks for a function registered with this name and loads it.
llm_ref: docker_llm: This is a reference to docker_llm in the llms: section. NAT:
1. Looks up docker_llm in the llms: section
2. Loads the LLM configuration
3. Creates a LangChain LLM object (because framework_wrappers=[LLMFrameworkEnum.LANGCHAIN])
4. Wraps it for observability
5. Passes it to your function via _builder.get_llm(_config.llm_ref, ...)
tools_ref: [datetime]: This is a reference to the datetime function in the functions: section. NAT:
1. Looks up the name (datetime) in the functions: section
2. Loads the function’s configuration
3. Creates a LangChain tool object
4. Wraps it for observability
5. Passes it to your function via _builder.get_tools(_config.tools_ref, ...)
max_iterations: 15, verbose: false: These fields map directly to your WebSearchAgentFunctionConfig Pydantic model. NAT validates that these fields exist and have the correct types.

Why references matter:

This is NAT’s dependency injection pattern in action. Instead of:

# Traditional approach - hardcoded dependencies
llm = ChatOpenAI(...)  # Hardcoded LLM
tools = [search_tool, datetime_tool]  # Hardcoded tools

You use references:

# NAT approach - reference-based dependencies
workflow:
  llm_ref: docker_llm      # Reference to llms:docker_llm
  tools_ref: [datetime]     # Reference to functions:datetime

Benefits:

Configuration-driven: Swap LLMs, tools, and parameters via config without code changes.
Automatic validation: NAT validates references exist and types match.
Observability: NAT tracks which LLM and tools were used automatically.
Composition: Multiple workflows can share the same LLM and tool definitions.

How the Configuration Connects to Your Code

Let’s trace how this configuration connects to the code we wrote:

1. When you run nat run --config_file config.yml:

NAT reads config.yml and finds workflow._type: web_search_agent
NAT looks up the entry point: web_search_agent.register
NAT imports web_search_agent.register, which triggers @register_function
The function is registered with WebSearchAgentFunctionConfig

2. NAT creates the function:

NAT parses workflow: section and validates it against WebSearchAgentFunctionConfig

NAT creates a WebSearchAgentFunctionConfig instance:

config = WebSearchAgentFunctionConfig(
    llm_ref=LLMRef(name="docker_llm"),  # Reference object
    tools_ref=[
        FunctionRef(name="datetime")
    ],
    max_iterations=15,
    verbose=False
)

NAT calls web_search_agent_function(config, builder)

3. Your function executes:

Your code calls: llm = await _builder.get_llm(_config.llm_ref, ...)
- NAT looks up llm_ref.name (“docker_llm”) in llms: section
- NAT loads the LLM configuration
- NAT creates a LangChain LLM object with your settings
- NAT wraps it for observability
- NAT returns it to your function
Your code calls: tools = await _builder.get_tools(_config.tools_ref, ...)
- NAT looks up each tools_ref name (“datetime”) in functions: section
- NAT loads each function’s configuration
- NAT creates LangChain tool objects
- NAT wraps them for observability
- NAT returns them to your function
Your LangChain code creates the agent with these components
NAT tracks everything automatically: tokens, timing, errors, etc.

Key insight: The configuration file is the glue that connects your code to NAT’s infrastructure. It’s not just settings—it’s a declarative way to define dependencies, swap components, and enable automatic observability.

Why This Structure Matters

This configuration pattern is what makes NAT powerful:

Separation of concerns: Components (LLMs, tools) are defined separately from how they’re used (workflow).
Configuration-driven: Swap components without code changes.
Automatic validation: NAT validates references and types at startup.
Observability by default: NAT tracks which components were used automatically.
Composability: Reuse LLM and tool definitions across multiple workflows.

What’s next: With the configuration in place, our agent is now ready to run. The agent will use the docker_llm and the datetime tool to answer questions. We can add additional tools later as needed.

Running Your Workflow

Now that we have our workflow configured, let’s see how to run it. NVIDIA NeMo Agent Toolkit provides three main CLI commands for different use cases:

1. nat run — Run a Single Query

This command runs your workflow once with a single input query. Use this for testing, debugging, or one-off queries.

nat run --config_file=src/web_search_agent/configs/config.yml --input 'hello world!'

What it does:

Loads your configuration from config.yml
Initializes the workflow (LLM, tools, agent)
Runs the agent with your input query
Prints the result to the console
Exits after completion

When to use it:

Testing: Quick tests to verify your workflow works
Debugging: See immediate output when fixing issues
One-off queries: Single questions or tasks
Development: Iterative testing during development

Example output: When you run the command, NAT will:

Load and validate your configuration
Show a configuration summary
Execute your workflow
Display the result

❯ nat run --config_file=src/web_search_agent/configs/config.yml --input 'hello world!'

2025-11-01 11:41:39 - INFO     - nat.cli.commands.start:192 - Starting NAT from config file: 'src/web_search_agent/configs/config.yml'

Configuration Summary:
--------------------
Workflow Type: web_search_agent
Number of Functions: 1
Number of Function Groups: 0
Number of LLMs: 2
Number of Embedders: 1
Number of Memory: 0
Number of Object Stores: 0
Number of Retrievers: 0
Number of TTC Strategies: 0
Number of Authentication Providers: 0

2025-11-01 11:41:43 - INFO     - nat.front_ends.console.console_front_end_plugin:102 - --------------------------------------------------
Workflow Result:
['Hello! How can I assist you today?']
--------------------------------------------------

What the output tells you:

Configuration Summary: NAT validates your config and shows what components it detected (1 function: datetime, 2 LLMs: docker_llm and niprgpt_llm, 1 embedder: docker_embedder).
Workflow Result: The agent’s response to your input query.
Timestamps: Each operation is logged with timestamps for observability.

2. nat eval — Evaluate Workflow Performance

This command evaluates your workflow against a test dataset. Use this for performance testing, benchmarking, or validation.

nat eval --config_file=src/web_search_agent/configs/config.yml

What it does:

Loads your configuration from config.yml
Runs your workflow against evaluation datasets (if configured)
Measures performance metrics (accuracy, latency, token usage)
Generates evaluation reports
Tracks performance over time

When to use it:

Performance testing: Measure response times and token usage
Quality assurance: Validate workflow accuracy against test cases
Benchmarking: Compare different configurations or models
Regression testing: Ensure changes don’t break existing functionality
Production validation: Test workflows before deployment

Example output (without evaluation dataset configured):

❯ nat eval --config_file=src/web_search_agent/configs/config.yml

2025-11-01 11:43:12 - INFO     - nat.eval.evaluate:446 - Starting evaluation run with config file: src/web_search_agent/configs/config.yml

2025-11-01 11:43:12 - INFO     - nat.eval.evaluate:484 - No dataset found, nothing to evaluate

Note: For nat eval to work, you need to configure evaluation datasets in your config file. Without a dataset configured, NAT will report “No dataset found, nothing to evaluate.” You can add evaluation datasets to your config file to test your workflow against test cases and measure performance.

3. nat serve — Start an API Server

This command starts a REST API server that exposes your workflow as an HTTP endpoint. Use this for production deployments or integration with other applications.

nat serve --config_file=src/web_search_agent/configs/config.yml

What it does:

Loads your configuration from config.yml
Starts an HTTP server (typically on http://localhost:8000)
Exposes your workflow as a REST API endpoint
Enables HTTP requests to interact with your agent
Keeps the server running until you stop it

When to use it:

Production deployment: Deploy workflows as services
API integration: Connect workflows to web applications, mobile apps, or other services
Remote access: Allow external systems to use your workflow
Testing integrations: Test how other applications interact with your workflow
UI access: NAT’s built-in UI can connect to running servers

API endpoint: Once the server is running, you can send HTTP requests to your workflow using the /generate endpoint:

curl -X POST http://localhost:8000/generate \
  -H "Content-Type: application/json" \
  -d '{"input_message": "What is the current date?"}'

Request format: The /generate endpoint expects a JSON body with an input_message field:

{
  "input_message": "string"
}

Response format: The endpoint returns a JSON response with a value field containing the agent’s response:

{
  "value": "The current date is November 1, 2025."
}

Available endpoints: NAT’s API server provides multiple endpoints:

/generate: Execute the workflow once and return the result (non-streaming)
/generate/stream: Execute the workflow with streaming response
/generate/full: Execute the workflow with full intermediate steps
/chat: Chat interface with conversation history
/chat/stream: Streaming chat interface
/v1/chat/completions: OpenAI-compatible chat completions endpoint

Benefits of using nat serve:

Scalability: Handle multiple concurrent requests
Observability: NAT tracks all requests automatically
Integration: Easy to integrate with existing systems
UI access: Use NAT’s built-in web UI to interact with your workflow
Production-ready: Includes error handling, logging, and monitoring

Choosing the Right Command

Use Case	Command	Why
Quick test or debugging	`nat run`	Immediate feedback, simple one-off execution
Performance testing or validation	`nat eval`	Comprehensive metrics and evaluation reports
Production deployment or API access	`nat serve`	Persistent service, HTTP API, integration-ready
Development and iteration	`nat run`	Fast feedback loop during development
Integration testing	`nat serve`	Test how external systems interact with workflow
Quality assurance	`nat eval`	Validate against test datasets

For this tutorial: Start with nat run to test your workflow, then use nat serve if you want to access it via HTTP or use NAT’s web UI.

Creating the Web Search Tool

Now let’s add web search functionality to our agent. We’ll create a custom tool that uses DuckDuckGo Search to query the web. Since we’ve already covered the NAT function pattern, we’ll focus on what’s new here.

1. File Organization

For better organization, we’ll place the tool in a tools directory:

src/web_search_agent/
├── __init__.py
├── register.py
├── web_search_agent.py
└── tools/
    └── web_search_tool.py

2. Creating the Web Search Tool

Create src/web_search_agent/tools/web_search_tool.py:

import asyncio
import logging

from nat.builder.builder import Builder
from nat.builder.framework_enum import LLMFrameworkEnum
from nat.builder.function_info import FunctionInfo
from nat.cli.register_workflow import register_function
from nat.data_models.function import FunctionBaseConfig

logger = logging.getLogger(__name__)

class WebSearchToolConfig(FunctionBaseConfig, name="web_search_tool"):
    pass

@register_function(config_type=WebSearchToolConfig, framework_wrappers=[LLMFrameworkEnum.LANGCHAIN])
async def web_search_tool_function(_config: WebSearchToolConfig, _builder: Builder):

    from ddgs import DDGS

    async def _search(query: str) -> str:
        """
        Searches the web for the given query.

        Args:
            query (str): The query to search for.

        Returns:
            str: The search results as a formatted string.
        """
        def _sync_search(q: str):
            ddgs = DDGS()
            results = list(ddgs.text(q, max_results=5))
            # Format results as a readable string
            formatted_results = []
            for i, result in enumerate(results, 1):
                if isinstance(result, dict):
                    title = result.get("title", "")
                    body = result.get("body", "")
                    formatted_results.append(f"{i}. {title}\n{body}")
                else:
                    formatted_results.append(f"{i}. {result}")
            return "\n\n".join(formatted_results) if formatted_results else "No results found."

        # Run the synchronous search in a thread pool
        result = await asyncio.to_thread(_sync_search, query)
        return result

    yield FunctionInfo.from_fn(_search, description=_search.__doc__)

What’s different from the agent function:

Simpler configuration: WebSearchToolConfig has no fields—just pass. Tools don’t need references to other components, so no configuration is required. NAT still requires a configuration class for consistency, but it can be empty.
Direct tool function: Instead of creating an agent executor, we create a simple async function that performs web search. This function will be wrapped as a LangChain tool.
Using DuckDuckGo Search: We import ddgs (the DuckDuckGo Search library) and use DDGS().text() to perform searches.
Async wrapper for sync code: Since ddgs is synchronous but our function must be async, we use asyncio.to_thread() to run the synchronous search in a thread pool. This prevents blocking the event loop:
```
result = await asyncio.to_thread(_sync_search, query)
```
Result formatting: We format the search results as a readable string that the agent can use. Each result includes a title and body.
Function docstring as description: We pass _search.__doc__ to FunctionInfo.from_fn() so the docstring becomes the tool’s description. This helps the LLM understand when to use this tool.

3. Updating register.py

Add the tool import to src/web_search_agent/register.py:

# flake8: noqa

# Import the generated workflow function to trigger registration
from .web_search_agent import web_search_agent_function
from web_search_agent.tools.web_search_tool import web_search_tool_function

Why this import is needed: Just like with the agent function, importing the tool triggers the @register_function decorator, which registers it with NAT’s registry.

4. Adding the Tool to Configuration

Update src/web_search_agent/configs/config.yml to include the web search tool:

functions:
  datetime:
    _type: current_datetime
  web_search_tool:
    _type: web_search_tool

# ... rest of config remains the same ...

workflow:
  _type: web_search_agent
  llm_ref: docker_llm
  tools_ref: [datetime, web_search_tool]  # Now includes web_search_tool
  max_iterations: 15
  verbose: false
  description: "A web search agent that uses the search and datetime tools to answer questions"

What changed: Added web_search_tool to the functions: section and included it in tools_ref: [datetime, web_search_tool].

5. Reinstalling the Workflow

After adding new code, you need to reinstall the workflow package so NAT can discover the new function:

nat workflow reinstall web_search_agent

This ensures NAT picks up the new web_search_tool function.

Key differences summary:

Aspect	Agent Function	Tool Function
Configuration	Has fields (llm_ref, tools_ref, etc.)	Empty (`pass`)
Complexity	Creates agent executor	Simple async function
Returns	Agent that processes queries	Direct search results
Dependencies	Needs LLM and tools from Builder	Uses external library (`ddgs`)
Use case	Orchestrates multiple tools	Performs a single task

What stays the same:

Same registration pattern (@register_function decorator)
Same framework wrapper (LLMFrameworkEnum.LANGCHAIN)
Same yield FunctionInfo.from_fn() pattern
Same import in register.py to trigger registration

Now your agent can search the web! Let’s see it in action:

Running the Complete Agent

With both the datetime and web_search_tool configured, your agent can now answer questions that require current information. Here’s an example query that uses both tools:

nat run --config_file=src/web_search_agent/configs/config.yml --input 'Who is the current US president! Get the todays data first.'

Example output:

❯ nat run --config_file=src/web_search_agent/configs/config.yml --input 'Who is the current US president! Get the todays data first.'

2025-11-01 12:07:16 - INFO     - nat.cli.commands.start:192 - Starting NAT from config file: 'src/web_search_agent/configs/config.yml'

Configuration Summary:
--------------------
Workflow Type: web_search_agent
Number of Functions: 2
Number of Function Groups: 0
Number of LLMs: 2
Number of Embedders: 1
Number of Memory: 0
Number of Object Stores: 0
Number of Retrievers: 0
Number of TTC Strategies: 0
Number of Authentication Providers: 0

2025-11-01 12:07:46 - INFO     - primp:464 - response: https://en.wikipedia.org/w/api.php?action=opensearch&profile=fuzzy&limit=1&search=query%3D%22current%20US%20president%202025%22%20%20%0AObserv 200

2025-11-01 12:07:46 - INFO     - primp:464 - response: https://www.bing.com/search?q=query%3D%22current+US+president+2025%22++%0AObserv&pq=query%3D%22current+US+president+2025%22++%0AObserv&cc=en 200

2025-11-01 12:07:54 - INFO     - primp:464 - response: https://en.wikipedia.org/w/api.php?action=opensearch&profile=fuzzy&limit=1&search=query%3D%22Who%20is%20the%20current%20president%20of%20the%20United%20States%20in%202025%3F%22%20%20%0AObserv 200

2025-11-01 12:07:56 - INFO     - primp:464 - response: https://search.brave.com/search?q=query%3D%22Who+is+the+current+president+of+the+United+States+in%202025%3F%22++%0AObserv&source=web 200

2025-11-01 12:08:02 - INFO     - nat.front_ends.console.console_front_end_plugin:102 - --------------------------------------------------
Workflow Result:
['The current US president is Donald Trump, who assumed office on January 20, 2025, as the 47th president.']
--------------------------------------------------

What the output shows:

Configuration Summary: Shows Number of Functions: 2, confirming both datetime and web_search_tool are registered and available.
Tool execution: The log messages show the agent:
- First getting the current date using the datetime tool
- Then performing web searches using the web_search_tool (you can see the search API calls in the logs)
- Combining the information to provide a complete answer
ReAct pattern in action: The agent uses a Reasoning + Acting loop:
- Reason: “I need to get today’s date first, then search for current president information”
- Act: Calls datetime tool, then web_search_tool
- Observe: Receives date information and search results
- Repeat: Refines search queries as needed
- Final answer: Combines all information into a complete response
Observability: NAT automatically tracks:
- Each tool call (you can see the web search API calls in the logs)
- Response times (timestamps show when each operation occurred)
- Tool usage patterns (the agent’s decision-making process)

What NAT provided automatically:

Automatic logging: Every tool call is logged with timestamps
Error handling: If a tool fails, NAT tracks it automatically
Performance tracking: NAT measures how long each tool call takes
Token counting: NAT tracks LLM input/output tokens automatically (not shown in this log level, but tracked internally)

This demonstrates NAT’s power: Your LangChain agent works exactly as it would without NAT, but now it has automatic observability, profiling, and production-ready features without any custom instrumentation.

Enabling Verbose Mode for Detailed Reasoning

To see the agent’s reasoning process in detail, you can enable verbose mode. This shows you the ReAct loop in action—how the agent thinks, decides which tools to use, and processes the results.

Update the configuration:

In src/web_search_agent/configs/config.yml, change verbose: false to verbose: true:

workflow:
  _type: web_search_agent
  llm_ref: docker_llm
  tools_ref: [datetime, web_search_tool]
  max_iterations: 15
  verbose: true  # Changed from false to true
  description: "A web search agent that uses the search and datetime tools to answer questions"

Run the agent again:

nat run --config_file=src/web_search_agent/configs/config.yml --input 'Who is the current US president! Get the todays data first.'

Verbose output:

❯ nat run --config_file=src/web_search_agent/configs/config.yml --input 'Who is the current US president! Get the todays data first.'

2025-11-01 12:10:13 - INFO     - nat.cli.commands.start:192 - Starting NAT from config file: 'src/web_search_agent/configs/config.yml'

Configuration Summary:
--------------------
Workflow Type: web_search_agent
Number of Functions: 2
Number of Function Groups: 0
Number of LLMs: 2
Number of Embedders: 1
Number of Memory: 0
Number of Object Stores: 0
Number of Retrievers: 0
Number of TTC Strategies: 0
Number of Authentication Providers: 0

> Entering new AgentExecutor chain...

Thought: I need to get the current date and time first to ensure the data is up-to-date.
Action: datetime
Action Input:
ObservThe current time of day is 2025-11-01 16:10:36 +0000

Action: web_search_tool
Action Input: current US president 2025
Observ2025-11-01 12:10:42 - INFO     - primp:464 - response: https://en.wikipedia.org/w/api.php?action=opensearch&profile=fuzzy&limit=1&search=current%20US%20president%202025%20%20%0AObserv 200

2025-11-01 12:10:43 - INFO     - primp:464 - response: https://search.brave.com/search?q=current+US+president+2025++%0AObserv&source=web 200

1. Wikipedia Second presidency of Donald Trump - Wikipedia
1 day ago - Throughout the first 100 days of his presidency, he implemented tariffs on multiple different countries, though mainly China, Mexico, and Canada, leading to retaliation. On April 2, 2025 , a day Trump nicknamed "Liberation Day", he announced a 10% universal import duty on all goods brought into ...

2. Wikipedia President of the United States - Wikipedia
1 week ago - In addition, nine vice presidents have become president by virtue of a president's intra-term death or resignation. In all, 45 individuals have served 47 presidencies spanning 60 four-year terms. Donald Trump is the 47th and current president ...

3. Wikipedia Donald Trump - Wikipedia
18 hours ago - He also won the popular vote with ... as an extraordinary comeback. Trump began his second term upon his inauguration on January 20, 2025 ....

4. Wikipedia Second inauguration of Donald Trump - Wikipedia
3 weeks ago - The inauguration of Donald Trump as the 47th president of the United States took place on Monday, January 20, 2025. Due to freezing temperatures and high winds, it was held inside the U.S. Capitol rotunda in Washington, D.C. It was the 60th ...

5. World Economic Forum The outlook for US President Trump's second term | World Economic Forum
Less than 24 hours after Donald Trump was sworn in as the 47th president of the United States, a panel of experts at the 2025 Annual Meeting in Davos, Switzerland, discussed how the global reception to the new president runs the gamut from ...

Thought: The search results confirm that Donald Trump is the current US president as of 2025.
Final Answer: The current US president is Donald Trump.

> Finished chain.

2025-11-01 12:10:52 - INFO     - nat.front_ends.console.console_front_end_plugin:102 - --------------------------------------------------
Workflow Result:
['The current US president is Donald Trump.']
--------------------------------------------------

What verbose mode shows:

ReAct reasoning loop: You can see the agent’s complete thought process:
- Thought: The agent’s reasoning (e.g., “I need to get the current date and time first”)
- Action: Which tool the agent chooses to use (e.g., datetime, web_search_tool)
- Action Input: What input the agent passes to the tool
- Observation: The result from the tool
- Thought (again): The agent processes the observation and decides the next step
- Final Answer: The agent combines all information into a response
Tool execution details: You can see:
- Which tools are called and in what order
- What inputs each tool receives
- What results each tool returns
- How the agent uses those results
Decision-making process: You can understand:
- Why the agent chose a particular tool
- How the agent processes tool results
- How the agent combines multiple pieces of information

When to use verbose mode:

Development: When building and debugging agents
Learning: To understand how ReAct agents work
Debugging: When troubleshooting why an agent isn’t working correctly
Optimization: To see if the agent is using tools efficiently

When not to use verbose mode:

Production: Verbose output can be noisy and slow down execution
Automation: When running agents in automated pipelines
Performance: For faster execution and cleaner logs

This verbose output demonstrates NAT’s integration with LangChain: You get all of LangChain’s debugging features (like verbose mode) while also having NAT’s automatic observability, profiling, and production features.

Try it yourself: Experiment with different queries that require web search:

nat run --config_file=src/web_search_agent/configs/config.yml --input "What are the latest news about AI agents?"

nat run --config_file=src/web_search_agent/configs/config.yml --input "Who won the Chiefs versus Commanders football game? What was the score and who was the MVP?"

Conclusion

Congratulations! You’ve successfully built a production-ready web-enabled research agent using NVIDIA NeMo Agent Toolkit and LangChain. Let’s recap what you’ve learned and why this matters.

Key Takeaways

Throughout this tutorial, we’ve covered:

Framework-Agnostic Architecture: NAT works alongside LangChain, not as a replacement. You kept your LangChain code unchanged while adding NAT’s powerful features.
Configuration-Driven Development: Everything is configured in YAML—from LLMs to tools to agent parameters. Swap components without touching code.
Automatic Observability: NAT tracks token usage, timing, and tool calls automatically. No custom instrumentation needed.
Function-Based Composition: Every component (agents, tools, workflows) is a function that can be reused and composed together.
Production-Ready from Day One: Built-in profiling, evaluation, and deployment features that would take weeks to build custom.

The Power of Less Code

Traditional approach (building the same agent with pure LangChain + custom tooling):

# What you'd need to build:
- Custom logging instrumentation
- Token counting logic
- Performance profiling
- Error tracking
- Retry mechanisms
- Configuration management
- Deployment scaffolding
- Evaluation framework
- API server setup
- Observability integrations (Phoenix, Weave, etc.)

# Result: Weeks of custom development code

With NVIDIA NeMo Agent Toolkit:

# What you built:
- Agent function: ~50 lines (pure LangChain)
- Tool function: ~40 lines (pure business logic)
- Configuration file: YAML
- Registration: 2 import statements

# Result: Same functionality + automatic observability + production features

The difference: Instead of building infrastructure, you build agents. NAT handles the production-grade features automatically.

What Makes NAT Powerful

Zero Framework Lock-In: Your LangChain code works exactly as it would without NAT. You can switch frameworks (LlamaIndex, CrewAI) or remove NAT entirely without rewriting your logic.
Configuration Over Code: Want to swap LLMs? Change one line in config.yml. Need different tools? Update tools_ref. No code changes required.
Observability by Default: Every function call, token usage, and timing is tracked automatically. NAT provides the observability infrastructure that most teams spend weeks building.
Composability: Your agent function, tool functions, and workflows are all reusable components. Build once, compose in multiple ways.
Production Features Built-In: Profiling, evaluation, deployment, and observability are not add-ons—they’re part of the foundation.

Real-World Impact

Before NAT:

Weeks of infrastructure development before you can deploy agents to production
Custom logging and observability code for every agent
Manual token tracking and cost monitoring
Custom evaluation frameworks for quality assurance
Tight coupling between framework choice and deployment strategy

After NAT:

Days (or hours) to production-ready agents
Automatic observability for all agents
Built-in profiling and cost tracking
Integrated evaluation framework
Framework-agnostic deployment

The Bottom Line

NVIDIA NeMo Agent Toolkit doesn’t replace your existing agent code—it amplifies it. By understanding NAT’s architecture:

You can keep using your favorite framework (LangChain, LlamaIndex, CrewAI)
You gain production features automatically without custom code
You can iterate faster because infrastructure is handled for you
You get enterprise-grade observability out of the box

The agent you built in this tutorial demonstrates all of these principles:

✅ Pure LangChain code (no NAT-specific changes)
✅ Configuration-driven (swap LLMs/tools via YAML)
✅ Automatic observability (token tracking, timing, logging)
✅ Production-ready (can deploy with nat serve immediately)
✅ Framework-agnostic (works with any OpenAI-compatible LLM)

Next Steps

Now that you understand the fundamentals, you can:

Explore Advanced Features: Add memory modules, retrieval systems, multi-agent workflows, or custom evaluators.
Integrate with Observability Platforms: Connect to Phoenix, Weave, Langfuse, or OpenTelemetry for deeper insights.
Build More Tools: Create custom tools for your specific use cases—database access, API integrations, or domain-specific logic.
Deploy to Production: Use nat serve or integrate with your existing deployment infrastructure.
Experiment with Different Frameworks: Try the same pattern with LlamaIndex or CrewAI—the structure remains the same.

Complete Example Code

By the time you read this, the complete source code for this tutorial is available on GitHub. The repository includes:

Complete agent implementation
Web search tool
Configuration files
Additional examples and variations

GitHub Repository: The complete example agent from this tutorial is available at https://github.com/phansiri/nvidia-nat-web-search-agent (or check the repository linked in the Further Resources section below).

You can use this as a template for your own agents or as a reference when building custom workflows.

Final Thoughts

NVIDIA NeMo Agent Toolkit represents a shift from “building infrastructure” to “building agents.” By understanding its architecture—configuration-driven design, function composition, and automatic observability—you can build production-ready agents faster and with less code.

The power isn’t in the complexity—it’s in the simplicity. NAT handles the hard parts (observability, profiling, deployment) so you can focus on what matters: building agents that solve real problems.

Image credit: Image

Further Resources:

NVIDIA NeMo Agent Toolkit Tutorial 1.3 with LangChain/LangGraph in November 2025

What is NVIDIA NeMo Agent Toolkit?

Why Choose NVIDIA NeMo Agent Toolkit Over Pure LangChain or CrewAI?

What We’ll Build

Agent Overview

Technical Stack

The Power of Bringing Existing Agents into NAT

Why This Showcases NAT’s Power

Example Use Cases

Installation

Prerequisites

Install NVIDIA NeMo Agent Toolkit

Verify Installation

Create a New Workflow Project

Project Structure Overview

Understanding Each Component

Why This Structure Helps

Additional Dependencies

Customize the Workflow

Creating the Web Search Agent

Understanding the Imports

The Configuration Class: WebSearchAgentFunctionConfig

The Registration Decorator

Getting Components from Builder

Creating the LangChain Agent

The Response Function

Why This Structure Matters

Registering the Function: register.py

Configuring the Workflow: config.yml

Understanding the Configuration Structure

How the Configuration Connects to Your Code

Why This Structure Matters

Running Your Workflow

Choosing the Right Command

Creating the Web Search Tool

Running the Complete Agent

Enabling Verbose Mode for Detailed Reasoning

Conclusion

Key Takeaways

The Power of Less Code

What Makes NAT Powerful

Real-World Impact

The Bottom Line

Next Steps

Complete Example Code

Final Thoughts

Related Posts

Starting to Build AI Agents with LangGraph in October 2025

Building AI Agents with AWS Strands in October 2025

The Configuration Class: `WebSearchAgentFunctionConfig`

Registering the Function: `register.py`

Configuring the Workflow: `config.yml`
